SALIENT FEATURES
• 30 CBM / HR CAPACITY
• Separate weighing system for cement and water with 3 load cells each
• 1000 liter PAN Mixer with replaceable Liners of ultra 2000
• Replaceable ST 52 Arm Guards
• Fully Automatic Microprocessor based PLC with SCADA software
• Separate Control cabin with PC Printer and UPS
• Available with Dragline Scrapper system and compartment Bin type aggregate storage

Standard Features

• Batching plant
• Control cabin
• Boom assembly 10.5 m
• Air compressor 2 HP
• Admisture Batching system with pump
• Computer with Inkjet Printer & UPS
• Screw feeder 168mm dia x 10.5m



POWER REQUIREMENT        GPM500DL    GPM500CB

PAN Mixer                                    22kw          22kw

Screw Conveyor(7.5kwx3Max) 22.5kw      22.5kw

Air Compressor                           1.5kw        1.5kw

Water Pump                                3.7kw       3.7kw

Admixture System & Vbrator        1kw           1kw

Skip Hoist Motors (2x4kw)           8kw          8kw

Drag Line Scrapper system            7.87kw        --

Total (Approx)                              67kw           60kw
